Roughness parameter

Ra,Rz,Rq,Rt

Tracing length

6mm

Tracing speed

1.0mm/sec

Cut-off lengths

0.25mm/0.8mm/2.5mm

Evaluation length

1.25mm/4.0mm/5.0mm

Measuring range

Ra: 0.05-10.0μm Rz: 0.1-50μm

Accuracy

±5%

Repeatability

<12%

Radius and angle of the stylus point

Diamond,Radius : 10μm±1μm

Angle: 90°(+5°or -10°)

Power supply

3.7V Li-ion battery

Recharging time

3 hours

Operating temperature

-20-40 ℃

Relative humidity

<90%

Dimensions (L×W×H)

106×70×24mm

Weight

200g
